Custom CNC Milled Black Anodized Aluminum Mounting Bracket
Custom CNC Milling · OEM / ODM Manufacturing
Custom CNC Milled Black Anodized Aluminum Mounting Bracket
A compact CNC-milled component with a curved interface profile, mounting holes, raised upper geometry, and a black anodized appearance. Shenzhen Perfect Precision Products Co., Ltd. manufactures drawing-based aluminum machined parts for OEM engineers, equipment manufacturers, and procurement teams.
Send your 2D drawing or 3D CAD file for a manufacturability review, material confirmation, finish review, and project quotation.
Built Around the Requirements That Affect Fit
Drawing-Based CNC Milling
Custom geometry is reviewed and manufactured from the buyer’s controlled drawing or CAD model.
Curved and Recessed Features
Internal profiles are reviewed for tool access, stable workholding, and deburring requirements.
Black Anodized Finish
Finish requirements can be coordinated against the required cosmetic or functional specification.
Precision Capability
The factory states a general machining capability of ±0.01 mm; tighter features remain project-dependent.
Prototype to Repeat Production
Prototype, small-batch, pilot, and repeat-production options are reviewed according to the drawing and capacity plan.
Product Specifications
Product-Specific Selling Points
Curved Interface Geometry
Mating radius and datum scheme are confirmed during engineering review to ensure assembly fit.
3/4/5-Axis CNC Strategy
Matched to compact 3D features for tool access, setup control, and feature visibility.
Custom Anodizing Control
Black anodized appearance coordinated with specific coating thickness and masking needs.
Strict Dimensional Control
Hole size and true position identified to align with features critical to the customer’s assembly.
Customization and RFQ Requirements
For an accurate quotation, please provide as much of the following information as available:
- 2D engineering drawings
- 3D CAD models (STEP/IGS)
- Material grade & temper
- Required quantities
- Critical dimensions & tolerances
- Thread standards
- Anodizing specifications
- Surface roughness requirements
- Inspection document needs
- Packaging & Delivery dates
Frequently Asked Questions
+ Can you manufacture the part from our drawing?
+ What tolerance can you achieve?
+ Can you provide a black anodized finish?
Request a Quote for Your Custom Aluminum Component
The engineering team can review the geometry, identify missing requirements, recommend a suitable machining route, and prepare a project-based quotation.
